Server Technology PRO2 Switched POPS C2WG48TE-5CAE2M99 - Master - power distribution unit (rack-mountable) - AC 415 V - 17.3 kW - 3-phase WYE (star) - Ethernet 10/100, RS-232 - input: NEMA L22-30P - output connectors: 48 (30 x IEC 60320 C13, 18 x IEC 60320 Cx)

The Server Technology PRO2 Switched POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS and POPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input and at each output. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP.

• Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more
• Star Multi-Linking provides the ability to link up to four power circuits using one IP address
• Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets
• Monitors current at each breaker branch and provides SNMP-based alerts and emails on high usage that risks a tripped circuit
• Three-phase power is wired in an alternating fashion per outlet for simplified load balancing, reduced cord lengths, and better airflow
• Receptacles have high retention and are compatible with P-Lock type power cords
• Tested and approved for safe and reliable operation in 60 °C data center environments
